Juniper Switch: Getting Started with Junos CLI

Coming from Cisco, Junos felt different. The commit model threw me off at first - you make changes, but nothing happens until you commit. Once I got used to it, I actually prefer it. You can stage multiple changes and apply them atomically.

Here's how I configure a Juniper switch from factory defaults.

Initial Setup

Set hostname and domain:

set system host-name SW-CORE-01
set system domain-name example.com

Configure management interface:

set interfaces ge-0/0/0 unit 0 family inet address 192.168.1.2/24

Add default route:

set routing-options static route 0.0.0.0/0 next-hop 192.168.1.1

Enable SSH:

set system services ssh

Nothing happens yet. You have to commit.

The Commit Model

This is what makes Junos different. All your changes sit in a candidate configuration until you commit:

commit

If there's a syntax error or conflict, the commit fails and nothing changes. This is safer than Cisco's immediate application model.

Useful commit options:

commit check          # Validate without applying
commit confirmed 5    # Auto-rollback in 5 minutes unless confirmed
commit comment "Added VLAN 10"

I use commit confirmed for remote changes. If I accidentally lock myself out, the switch rolls back automatically.

VLAN Configuration

Create a VLAN:

set vlans Sales vlan-id 10
set vlans Engineering vlan-id 20

Assign ports:

set interfaces ge-0/0/1 unit 0 family ethernet-switching vlan members Sales
set interfaces ge-0/0/2 unit 0 family ethernet-switching vlan members Engineering

Create trunk port:

set interfaces ge-0/0/24 unit 0 family ethernet-switching interface-mode trunk
set interfaces ge-0/0/24 unit 0 family ethernet-switching vlan members [Sales Engineering]

Link Aggregation

Junos calls it aggregated Ethernet (ae):

set chassis aggregated-devices ethernet device-count 2
set interfaces ae0 aggregated-ether-options link-speed 1g
set interfaces ae0 aggregated-ether-options lacp active

set interfaces ge-0/0/1 ether-options 802.3ad ae0
set interfaces ge-0/0/2 ether-options 802.3ad ae0

Firewall Filters

Junos firewall filters are like extended ACLs:

set firewall family inet filter BLOCK-SSH term 1 from protocol tcp
set firewall family inet filter BLOCK-SSH term 1 from destination-port 22
set firewall family inet filter BLOCK-SSH term 1 then discard
set firewall family inet filter BLOCK-SSH term 2 then accept

set interfaces ge-0/0/1 unit 0 family inet filter input BLOCK-SSH

The explicit accept term at the end is important - Junos has an implicit deny.

Verification Commands

show configuration              # Full config
show vlans                      # VLAN status
show interfaces terse           # Interface summary
show ethernet-switching table   # MAC table
show lacp interfaces            # LAG status
show system commit history      # Commit log

Rolling Back

Made a mistake? Junos keeps the last 50 configurations:

show system rollback compare 0 1    # Diff between current and previous
rollback 1                          # Restore previous config
commit                              # Apply the rollback

This has saved me more than once.

Key Takeaways

• Changes don't apply until you commit - this is safer than immediate application
• Use commit confirmed for remote changes to avoid lockouts
• VLAN membership is set on the interface, not the VLAN
• Firewall filters need an explicit accept term at the end
• Keep rollback in mind - it's your safety net
